Horizontal Boring Machine
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Application | Industrial |
| Weight | 100-1000kg |
| Voltage | 220V |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
We present 'WMW-New Bharat' Horizontal Boring Machine to the customers. Our Horizontal Boring Machine can be availed in various models such as BFT-80, 110 & 110/ 3 and also available in CNC version BFP-100 & 125 Floor Type.
Characteristic Features of these machines
- Low friction transmission makes maximum power available at the tool for high material removal
- Very wide range of speeds and feeds to take care of all the possible machining problems from the smallest to the largest working diameter
- High quality design of the bearing system for the sleeve and outer hollow spindle
- All operating elements are ergonomically arranged
- Close manufacturing tolerances due to precision scraped/ground slide ways and fine positioning by dial gauges, vernier or digital readout
- Geometric tests confirm to DIN-8620
Details
|
Specification |
BFT-80 |
BFT-110 |
|
Diameter of work spindle |
80 |
110 |
|
Work spindle movment |
710 |
710 |
|
Max. Diameter-boring |
450 |
500 |
|
Max. Diameter-facing |
800 |
900 |
|
Spindle nose taper (Morse) |
MT 5 |
MT6 |
|
Rotary table clamping surface |
900x1120 |
1250-1400 |
|
Max. Distance of fixed stay bearing from facing head |
2240 |
2240 |
|
Table movement-longitudinal (with stay) |
1250 |
1250/1600 |
|
Table movement-crosswise |
1000 |
1600 |
|
Max height of spindle center over table |
900 |
1000/1200 |
|
Max. Weight of workpiece |
2000 kg |
2500 kg. |
|
Rotary table-T-slot width/distance |
22/125 |
22/140 |
|
Rotary table centering diameter |
90H7 |
140H7 |
|
Facing head diameter |
500 |
630 |
|
Facing slide travel |
200 |
200 |
|
Facing head-T-slot width/distance |
18/300 |
18/300 |
|
Facing head cnetering diameter |
250H7 |
400 H7 |
|
Fixed stay bearing length |
(80 H7 with bush) 120 |
(with bush) 200 200 |
|
Spindle Speed |
||
|
Range I for spindle and |
6 steps |
9 steps |
|
Facing head |
2.8 to 16 r.p.m |
8 to 50 RPM |
|
Range II for spindle and |
6 steps |
9 steps |
|
Facing head |
22.4 To 125 r.p.m |
31.5 to 200 RPM |
|
Range III for spindle |
6 steps |
9 steps |
|
Rapid idle traverse per minute, identically to all |
180 to 1000 r.p.m |
200 to 1250 RPM |
|
Movements, except radial slide of facing head |
1400 |
2500 |
|
Rapid Traverse per minute of radial slide |
280 |
750 |
|
Feed valves for work spindle, headstock table |
||
|
For all movements : (mm/rev.) |
||
|
Speed Range I |
36 steps |
24 steps |
|
0.15 to 40 |
0.1 to 20 |
|
|
Speed range II |
36 steps |
24 steps |
|
0.2 to 5.45 |
0.025 to 5 |
|
|
Speed range III |
36 steps |
24 steps |
|
(For Spindle only) |
0.0025 to 0.68 |
0.004 to 0.8 |
|
Feed per minute |
36 steps |
24 steps |
|
(Independent of spindle speed) |
2.17 to 580 |
5-100 |
|
Feed values for radial of facing head |
||
|
(A) II range (mm/rev.) |
72 steps |
48 steps |
|
0.0042 to 8.2 |
0.008 to 6.3 |
|
|
(B) Feed per minute |
36 steps |
48 steps |
|
0.44 to 113 |
0.252 to 320 |
|
|
Metric threads cutting (with spindle or longitudinal travel of table) |
0.25-0.3-0.5-0.6 |
0.1-0.125-0.2-0.25 |
|
0.75-1-1.25-1.5-2-2.53 |
0.4-0.5-0.8-1-1.25-2-2.5 |
|
|
4-5-6-8-10-12-20-24-40 |
4-5-8-10-16-20 |
|
|
Inche thread cutting : (TPI) |
48-40-32-24-20 |
48-24-12-6-3 |
|
(With spindle feed only) |
16-12-10-8-6-5-43 |
-- |
|
Total power : KW |
5.5 |
11 |
|
Net. Weight approx. |
7500 kg |
16000 kg. |
|
(with standard equipment) |
||
|
Space requirement ; meters (LxWxH) |
5.2.5x2.6 |
6x3.2x2.7 |
